S-46P-N : 46’’ FHD Studio Monitor with SFP module & Ember Protocol
The S-46P-N has the new designed mainboard for advanced stability and speedy processing. This monitor supports various video formats including 12G-SDI, HDMI and SFP. Also provides network control by Ember+ protocol and HDR with HDR EOTFs of PQ, HLG and SLog3.
46’’ FHD Studio Monitor with SFP module & Ember Protocol
Main Body Dimensions
Main Body 1070.6 x 637.5 x 76.4(mm) / 42.15 x 25.09 x 3.00(inch)
With Stand 1070.6 x 686.38 x 245(mm) / 42.15 x 27.02 x 9.65(inch)
Weight 26.3kg / 57.98lbs
Product Highlights
• 2 x 12G-SDI Input and Loopout
• 12G-SDI Input to 3G-SDI Downscale Output
• Processed Monitor Output
• Picture-by-Picture Display
• HDR (PQ, HLG, S-LOG3)
• Custom 3D LUT Import by USB Flash Drive
• Auto Detection of SDI Payload ID
• Image Capture & Overlay
• Waveform (YCbCr, RGB) / Vector Scope / Histogram
• Audio Level Meter / Audio Phase Meter
• Fast Mode
• Focus Assist / Marker
• Closed Caption in Multi Languages (CC-608, CC-708, OP47)
• Blue/Mono Only
• Timecode Display
• Remote Control & FW Update via Ethernet
• Dynamic UMD / Tally
• H Flip, V Flip
